Parker Polyflex
HOSE waterblast
10,000 to 20,000 psi
Flexible Lances
10,000 to 20,000 psi
Delivery Hose
20,000 psi Flexible Lances
Custom designed for internal tube cleaning with ProLance™ end fittings. The fittings are sized to travel in and out of tight locations and various applications.
2240D-025V34 = .17" ID Hose with a 17,400psi working pressure.
2245D-03V32 = .20" ID Hose with a 16,240psi working pressure.
2380N-04V00 = .25" ID Hose with a 13,200psi working pressure.
Flexible and light weight hose used to transfer water and/or other fluids from one part of the high-pressure waterjetting system to another.(i.e. pump to foot valve)
2380N-05V00 = .32" ID Hose with a 13,600psi working pressure.
2390N-06V13 = .40" ID Hose with a 10,300psi working pressure.
2244N-08V10 = .50" ID Hose with a 12,760psi working pressure.
High-pressure hose for maximum durability in cleaning tubes at 20,000 psi and above. Available with Nozzle Nipple end fittings.
2440D-025V37 = .15" ID Hose with a 31,900 psi working pressure.
2440D-03V37 = .20" ID Hose with a 26,100 psi working pressure.
2440N-04V37 = .25" ID Hose with a 23,780 psi working pressure.
20,000 psi Delivery Hose
36,000 psi Hose
40,000 psi Hose
Durable and reliable hose that is used when higher flow at 20,000 psi is required. Available with swivel nut connections for easy adaptability.
2440D-05V37 = .32" ID Hose with a 21,750 psi working pressure.
2440N-06V91 = .40" ID Hose with a 20,300 psi working pressure.
2440N-08V37 = .50" ID Hose with a 20,400 psi working pressure.
2640N-12V32 = .75" ID Hose with a 20,290 psi working pressure.
Specially-designed hose for “ULTRA-HIGH” pressure applications. Available with high-pressure tube nipple or Type “M” swivel end fittings.
2640D-03V32 = .20" ID Hose with a 36,230 psi working pressure.
2740D-05V32 = .33" ID Hose with a 36,230 psi working pressure.
2840D-08V34 = .50" ID Hose with a 36,000 psi working pressure.
Ideal for use in robotic waterjet cutting applications or to replace highpressure
rigid tubing. Available with high-pressure tube nipple or Type “M” swivel end fittings.
2640D-025V32 = .16" ID Hose with a 40,600 psi working pressure.
2740D-03V30 = .20" ID Hose with a 40,600 psi working pressure.
2840D-03V34 = .20" ID Hose with a 48,000 psi working pressure.
2840D-05V32 = .32" ID Hose with a 40,580 psi working pressure.
Oilfield Service Hose
HOSE Special applications
Constructed with a core tube material specially compounded for high-chemical resistance. With a high external collapse pressure resistance, they are well suited for deep water use. Available in long continuous lengths.
2380N-05V71 = .32" ID Hose with a
13,600 psi working pressure.
2244N-08V71 = .50" ID Hose with a
12,760 psi working pressure.
Collapse resistant hose suited for offshore oil exploration applications requiring internal pressure resistance and external pressure support. The 57CR series hose offers the ultimate in a lightweight kink and collapse
resistant Patent-Pending hose construction.
57CR-8, 1/2" ID Hose with a 5000 psi
working pressure.
57CR-16, 1" ID Hose with a 5000 psi
working pressure.
The Black Eagle is a flexible, chemical resistant alternative to steel pipe for high volume flow rate pumping, chemical injection, and well service cementing. Available in long lengths.
2640N-24V80, 1.5" ID Hose with a 10,000 psi working pressure.
2640N-32V80, 2" ID Hose with a 10,000 psi
working pressure.
High-Pressure Hydraulic Hose
Twin-Line and Multi-Line
Hose Bundle
Constructed with a core tube material specially compounded for high-chemical resistance. With a high external collapse pressure resistance, they are well suited for deep water use. Available in long continuous lengths.
2380N-05V71 = .32" ID Hose with a
13,600 psi working pressure.
2244N-08V71 = .50" ID Hose with a
12,760 psi working pressure.
The ChemJec™ series of hoses provide high working pressures with some hoses offering greater than 20,000 psi. Specially constructed
fluoropolymer core tube for increased chemical resistance.
2370M-34V10 = .25" ID Hose with a 6,475
psi working pressure.
2440M-08V30 = .50" ID Hose with a 16,000
psi working pressure.
2448M-04V30 = .25" ID Hose with a 24,000
psi working pressure.
A value-added service to solve tough routing applications, extensively used in high-pressure hand tool applications. Color coding is
available with Parker polyflex® Twin-Line hose.
2390N-04V12-D = .25" Hose with a 12,000
psi working pressure.
2380N-04V04-D = .25" Hose with a 16,240
psi working pressure.
2380N-04V02/04-D = .25" Hose with
10,150 psi working pressure (4:1).
High-Pressure Testing Hose
Special Hose Bundles
For use in high- and ultra-high pressure hydrostatic testing requirements, where durability and flexibility are required.
2380N-04V00 = .25" ID Hose with a 13,200 psi working pressure.
2440D-03V37 = .20" ID Hose with a
26,100 psi working pressure.
2640D-03V32 = .20" ID Hose with a
36,230 psi working pressure.
The specially formulated HP series hose has a thermoplastic elastomer core with aramid fiber reinforcement for high-pressure hydraulic, pneumatic and lubricating systems.
Non-conductive HP8 has an orange, non-perforated elastomeric cover.
HP, HP8 series = 3/16" to 3/8" ID Hose
with a 8000 to 10,000 psi working
pressure.
Hose bundles for offshore drilling and
special applications.
Product:............................Contact us
Sizes: ................................Contact us
Working Pressures:.........Contact us
